Verify reliability with an ESD monitor from SCS

Explore three options for a range of applications

When it comes to ESD protection, reliability should never be in question. And, with features suited for a variety of unique environments and applications, an SCS workstation monitor can offer your best defense against overvoltage and potential damage caused by electrostatic discharge. SCS offers three levels of protection to address varying requirements — so whether your focus is simple installation or communication across an entire network, you’ll find the ideal fit for any application.

Need help with selecting the right ESD monitor? Contact us!

724 Workstation Monitor

  • Adjustable Operator Test Voltage and Upper Limit

    Test voltage can be set to 9 or 16 volts; test limit can be set to 10 or 35 megohms.

  • Continuously Monitors Two Operator Dual-Wire Wrist Straps and One Work Surface Mat

    Visible and audible alarms indicate improper grounding of the operator and work surface.

  • Adjustable Audible Alarm

    Buzzer volume may be disabled or set to loud or soft.

  • Simple Installation and Setup

    Mounting hardware and wire management clips are included.

  • Top Seller

Iron Man® Plus Monitor

  • Digital Signal Processing Technology

    Applies a low test voltage to the operator (0.40V) for the handling of sensitive components.

  • Electrical Overstress (EOS) Detection

    Alarms if overvoltage from a tool is applied to a circuit board under assembly.

  • IPC-A-610 Appendix 3.1.1 EOS/ESD Prevention

    Current research indicates that voltages and spikes less than 0.5V are acceptable.

  • Operator Body Voltage Detection

    Alarms if the operator generates or comes in contact with a voltage that would be dangerous to an ESD-susceptible item.

WS Aware Monitor

  • Digital Signal Processing Technology

    Applies an ultra-low test voltage to the operator (0.50V) for the handling of sensitive components.

  • Dual Workstation Continuous Monitor

    Continuously monitors the path-to-ground integrity of two operators, two conductive or dissipative work surfaces, and two metal tools; meets ANSI/ESD S20.20 in accordance with ESD TR1.0-01-01.

  • EMI Monitoring on Metal Grounds

    Alarms of the grounded metal tools have high-frequency noise that could cause electrical overstress (EOS) damage.

  • NEW Ethernet Connectivity

    Provides network communication with static management program.

  • NEW Optical Relay Terminal

    Pairs with lights and buzzers for increased visibility.

Industry Applications 724 Iron Man Plus WS Aware
Contract Manufacturers
OEM
General Electronics Manufacturers
Medical Electronics
Disk Drive Assembly
Semiconductor Fabrication
